Solar panel entity · 200 W flexible laminate · Current
Renogy 200W 12V Flexible Monocrystalline Solar Panel
200 W flexible ETFE-laminated monocrystalline panel, 4.9 kg, with a published 16.7% module efficiency, Voc 23.9 V, Vmp 20.1 V, Isc 10.74 A, Imp 10.02 A. Half-cut 72-cell layout, MC4 output, IP68 junction box. The larger, higher-efficiency sibling of the 100W Flexible for curved van, camper and boat rooftops.
Machine summary · solar_panel · renogy-200w-flexible
- brand
- Renogy
- model_name
- 200W Flexible Monocrystalline
- release_status
- current
- rated_power_w_stc
- 200
- cell_type
- monocrystalline
- form_factor
- flexible
- output_connector
- MC4
- charge_controller_included
- false
- weight_kg
- 4.9
- confidence_level
- high
- source_last_checked
- 2026-08-10
- json_export
- /solar-panels/renogy-200w-flexible.json
Overview
This is Renogy's 200 W flexible panel: 72 half-cut monocrystalline cells laid out in an 18 by 4 grid, laminated between an ETFE front and a plastic back at roughly 3 mm thick, so it conforms to the curved roof of a van, camper or boat where a rigid panel cannot sit flat. Peak power is 200 W at STC with Voc 23.9 V, Vmp 20.1 V, Isc 10.74 A and Imp 10.02 A. Module efficiency is a published 16.7%, materially higher than the 100W Flexible's 14.9%, which Renogy attributes to the half-cut cell design and bypass diodes that also improve resistance to hotspots and partial shading. At 4.9 kg it is roughly half the weight of a comparable rigid 200 W mono panel. Output is MC4 via a 12 AWG cable, the junction box is IP68 and the solar connectors are IP67, and no charge controller is included: this is a raw component that feeds an external controller, which then feeds the battery. Maximum system voltage is 600 V DC and the panel is rated from -40 to 80 C.
Variant note: Current 200W 12V Flexible Monocrystalline (SKU RNG-200DB-72). Distinct from Renogy's 50W and 100W flexible variants (separate product pages, different spec tables), from the rigid 200W monocrystalline (RSP200DB-72 family), from the E.Flex 200W portable panel (RPP200EF-SE, a JS-hydrated page), and from the 200W N-Type high-efficiency panel.
Data note: All figures taken from Renogy's published Specifications block on 2026-08-10 (SKU RNG-200DB-72). Cell layout stated as 72 (18 x 4) half-cut monocrystalline cells of 6.5 x 3.3 in. Dimensions given as 1605 x 748 x 3 mm (63.2 x 29.4 x 0.1 in). Cable length converted from Renogy's stated 12 AWG 2.3 ft output cable (~0.7 m). The IP string is the manufacturer's exact statement: the panel body has NO separate IP rating, only the junction box (IP68) and solar connectors (IP67). Warranty: Renogy states a 5-year 90% output performance warranty for this panel, which is shorter than the 100W Flexible's tiered 25-year performance warranty; warrantyYears records the 5-year term. No PERC claim is made because the page does not state one for this model, only half-cut cell technology. outputConnector recorded as MC4 per Renogy's whole-line convention (the spec block names 'Solar Connectors: IP67' and a 12 AWG output cable but not the connector brand explicitly).
Specifications
Rated power, cell type, form factor, connector and weight come from official manufacturer sources; the exact claims and links are in the provenance table. Electrical characteristics and cell efficiency are recorded only where a numeric figure is published, and compatibility with any particular power station is recorded only where the manufacturer states it. A connector type is not a compatibility claim.
| Attribute | Value |
|---|---|
| Rated power (STC) | 200 W |
| Cell type | Monocrystalline |
| Form factor | Flexible laminate |
| Cell efficiency | 16.7% |
| Attribute | Value |
|---|---|
| Published values | Voc 23.9 V · Vmp 20.1 V · Imp 10.02 A · Isc 10.74 A |
| Attribute | Value |
|---|---|
| Output connector | MC4 |
| Output cable | 0.7 m |
| Charge controller included | No |
| Official compatibility statement | Renogy specifies this panel for 12 V systems with an appropriate charge controller. Maximum system voltage is 600 V DC. No compatibility with any specific power station is asserted; it feeds an external charge controller. |
| Attribute | Value |
|---|---|
| Weight | 4.9 kg (10.8 lb) |
| Dimensions unfolded (L × W × H) | 1,605 × 748 × 3 mm |
| Ingress protection | IP68 junction box / IP67 solar connectors (panel body has no separate IP rating) |
| Attribute | Value |
|---|---|
| Warranty | 5 years |
| Release status | Current |
| Market region | US |
Use cases
- Van, camper, boat or trailer rooftops where a rigid 200 W panel cannot sit flat on the curved surface
- Weight-critical installs: 4.9 kg for 200 W is roughly half the weight of a comparable rigid mono panel
- Higher-output flexible installs where the 100W Flexible is not enough wattage in the same construction
Strengths and weaknesses
Strengths
- Published NUMERIC module efficiency (16.7%), higher than the 100W Flexible's 14.9%
- Full published electrical characteristics (Voc, Vmp, Imp, Isc)
- Half-cut cell design with bypass diodes for better shade and hotspot resistance
- 4.9 kg for 200 W, materially lighter than a rigid 200 W mono panel
- IP68 junction box and IP67 solar connectors
Weaknesses
- 16.7% module efficiency is still below rigid mono panels (typically 20-22%): flexibility costs efficiency
- Panel body has no IP rating of its own, only the junction box and connectors do
- Warranty is a 5-year 90% output performance warranty, shorter than the 100W Flexible's 25-year performance tier
- No charge controller included (this is a component)
- Flexible ETFE surfaces are more susceptible to abrasion and delamination over time than glass-faced rigid panels
Where to buy
Affiliate disclosure: some links below are affiliate links — if you buy through one we may earn a commission at no extra cost to you. This never affects which products are indexed, how they are ranked, or the specifications shown; those come from official manufacturer sources only. As an Amazon Associate I earn from qualifying purchases. Full disclosure.
| Merchant | Price | Checked | Availability | Link |
|---|---|---|---|---|
| RenogyprimaryManufacturer direct | Not tracked | — | — | View at Renogy |
| AmazonaffiliateMarketplace | Not tracked | — | — | View at Amazon |
Sources and provenance
Core specifications come from official manufacturer sources only, with the exact claim text preserved per field. Spec sheets and manuals outrank marketing copy. See the methodology for the full policy.
| Field | Normalized value | Raw claim | Source | Confidence |
|---|---|---|---|---|
ratedPowerW | 200 | Maximum Power at STC: 200W | Official spec page — STC rating. | high |
cellType | monocrystalline | Cell Type: Monocrystalline (6.5x3.3); Number of Cells: 72 (18x4) | Official spec page — 72 half-cut monocrystalline cells. | high |
formFactor | flexible | Renogy 200W Flexible Solar Panel for RV & Off-Grid; Dimensions: 1605 x 748 x 3 mm (63.2 x 29.4 x 0.1 in) | Official product page — Flexible ETFE-laminated construction verified from the curved-panel product image and the 3 mm panel thickness. | high |
outputConnector | MC4 | Output Cables: 12 AWG (2.3 ft); Solar Connectors: IP67 | Official spec page — Renogy's standard-issue MC4 output; label inferred from the whole-line convention, consistent with the other Renogy panels in this index. | high |
efficiencyPercent | 16.7 | Module Efficiency: 16.7% | Official spec page — Numeric module efficiency published in the spec table. | high |
vocV | 23.9 | Open-Circuit Voltage (Voc): 23.9V | Official spec page | high |
vmpV | 20.1 | Optimum Operating Voltage (Vmp): 20.1V | Official spec page | high |
impA | 10.02 | Optimum Operating Current (Imp): 10.02A | Official spec page | high |
iscA | 10.74 | Short Circuit Current: 10.74A | Official spec page — Isc > Imp as expected. Page labels it 'Short Circuit Current' without the (Isc) abbreviation. | high |
weightKg | 4.9 | Weight: 4.9 kg / 10.8 lbs | Official spec page — Manufacturer's own metric value used verbatim. | high |
